Fireproof Earth Leakage Protection EDF 4P 500mA Rcbo Circuit Breaker

The EDF 500mA 4P 10/30 A Selective Connection (Baco) Edf 69-30-066

1. Application

Breaker are suitable in AC 50Hz, 250/440V circuit with overload and earth leakage protection. The rated current is adjustable from 10A up to 60A. User can select suitable current to better protection against overload and short circuit. The products comply with NFC 61450.

The EDF 500mA 4P 10/30 A Selective Connection (Baco) edf 69-30-066
disj EDF tétrapolaire bins 3.
Circuit Breakers tétrapolaires
Low voltage circuit breakers subscriber Baco For Price of 3 to 36 kVA: Cutting and blue sectionnent the plant as a whole, protect against overload/short circuit have a size adjustment to minimize power EDF contract signed provides the protection of people against indirect contact and prevent a fire by the level monitoring Isolation (Differential) the frequency selective, allow a full selection with the differentials 30 mA downstream devices (NF C 15-100) and strengthens immunity to pertubations resulting from atmospheric phenomena or other nuisance (mode) plombables certified NF C 62-411 (Differential) devices approved NF C 62-412 (devices not differentials)
250/440 V Weight 800 g
Product Features
Differential circuit breakers, 500 mA
Selective
Nominal current: 30 A (a)
I can be adjusted: 10/15/20/25/30 (a)
EDF nomenclature Number: 69 30 066

.

Technical Specifications

Outshell and installation dimensions

Electrical Circuit Breaker EDF Baco (500 mA Selective 4P 10/30 A) edf 69-30-066

DDC BACO Adjustable circuit breaker.pdf

500mA rcbo circuit breaker

500mA inline rcd protection device

EDF rcbo circuit breaker

Fireproof Earth Leakage Protection EDF 4P 500mA Rcbo Circuit Breaker Images
